Art.SG405 PFA內襯型氣動閥

Art.SG405 PFA內襯型氣動閥專為超高腐蝕性流體設計，閥體內襯PFA（聚全氟乙丙烯），具備卓越的耐酸鹼、耐高溫性能。搭配高性能氣動驅動器，廣泛應用於半導體、化工、超純水、電鍍及精密製程領域，確保流體系統長效穩定運作。

產品特色

• PFA內襯設計，極高耐腐蝕性
• 適用於強酸、強鹼、高純度流體系統
• 耐高溫、耐高壓，適合嚴苛工況
• 氣動驅動，反應快速，密封可靠
• 適用於半導體、化學製程、超純水設備

技術規格

尺寸 (Size)	1/2" ～ 4"（可訂製）
閥體材質 (Body Material)	碳鋼 / 不鏽鋼外殼，PFA內襯
氣缸材質 (Cylinder Material)	陽極處理鋁合金
工作壓力 (Working Pressure)	PN10～PN16（依尺寸與材質）
工作溫度 (Working Temperature)	-20℃ 至 +180℃
適用流體 (Applicable Fluids)	強酸、強鹼、超純水、化學藥液

Art.SG405 PFA Lined Pneumatic Valve

The Art.SG405 PFA lined pneumatic valve is specially designed for handling highly corrosive fluids. Featuring an internal PFA (Perfluoroalkoxy) lining, it offers superior resistance to acids, alkalis, and high temperatures. Combined with a high-performance pneumatic actuator, it is ideal for semiconductor, chemical processing, ultrapure water, and precision manufacturing applications.

Features

• PFA lining for exceptional chemical resistance
• Suitable for strong acids, alkalis, and ultrapure fluids
• High temperature and pressure tolerance
• Fast and reliable pneumatic actuation
• Ideal for semiconductor and chemical process industries

Technical Specifications

Size	1/2" ～ 4" (customizable)
Body Material	Carbon Steel / Stainless Steel with PFA lining
Cylinder Material	Anodized Aluminum Alloy
Working Pressure	PN10 to PN16 (depends on size and material)
Working Temperature	-20℃ to +180℃
Applicable Fluids	Strong acids, strong alkalis, ultrapure water, chemical liquids
